Features
T800 and T1100 carbon fiber layup offers ultralight weight without compromising on strength and stiffness.
One-piece, no-bond manufacturing on the drops, hoods and tops utilizes CADEX precision layup technique to eliminate the added weight and flex found in traditionally bonded bars.
72mm reach provides a swift transition between the tops and hoods for added control when switching hand positions.
125mm shallow drops for quick and easy movement from the hoods to the drops.
11-degree flare for total control when sprinting, attacking and descending.
Narrower position at the hoods combines with wider drops for watt-saving efficiency and control.
Integrated bar-and-stem construction and internal cable routing for improved aerodynamic performance.
Out-front computer mount included.
Compatible with OverDrive Aero steerer tubes, 1 1/8" compatible coming soon.
Specifications
Material: Carbon
Stem Angle: -10 degrees
Stem Clamp: OverDrive Aero
Stem Length: 80 / 90 / 100 / 110 / 120 / 130 / 140mm
Width (Drop to Drop): 360 / 380 / 400 / 420 / 440mm
Width (Hood to Hood): 340 / 360 / 370 / 390 / 410mm
Drop: 125mm (120mm for 360 / 380mm bar)
Reach: 72mm (68mm for 360 / 380mm bar)
Flare: 11 degrees for 400 / 420/ 440mm bar 8 degrees for 360/380 bar
Weight: 256g (420mm x 100mm bar)
Included Accessories: CADEX out-front computer mount, OverDrive Aero spacer
